Typical Applications
Medicine vials, jam jars, canned food
and soft drinks, shampoo bottles, oil containers, etc. Packaged as handy "pick and carry" consumer packs or large-size
distribution packs. Books, cassettes, discs, floor and wall tiles, chocolate in boxes, ice cream tubs, boxes and
trays or all types. Popular for price club and promotional applications.
Operation
 |
A simple rotary selector switch is set for the number of rows - 1, 2, 3 or 4 - as desired. |
 |
A sensor switch activates and the pusher
advances the row. |
 |
The pusher moves the collated group past the sealer. |
 |
The package is shrunk with
re-circulated hot air. |
 |
The product is conveyed in front of the pusher. |
 |
The number of rows is accumulated. |
 |
The package is sealed and conveyed through the shrink tunnel. |
 |
Before leaving the conveyor, the film is fan-cooled to achieve a tight, secure package. |
|

Available in custom sizes.
Can be easily integrated into your production line.
|
